Oscilloscope and Function Generator for myRIO

Choose Movement Consulting (CMC)

The Oscilloscope and Function Generator for myRIO helps you use the myRIO Student Embedded Device as a function generator or oscilloscope.
The Oscilloscope and Function Generator for myRIO is a software add-on for LabVIEW that you can use to turn your PC and myRIO Student Embedded Device into a 2-channel, 345 kS/s function generator. This function generator helps you create sine and square waves as well as configure amplitude, frequency, and offset. Alternatively, you can use this add-on to convert your hardware into a 2-channel oscilloscope that supports a ±10 V input range, 250 kHz maximum acquisition rate for each channel, and a 200 ms to 20 µs time/div range. This oscilloscope also features simultaneous sampling, continuous acquisition or single buffer, amplitude autoscaling, and signal inspection with cursors. Plus, you can modify the code included with the add-on to implement your own instrument functionality.
+ Read More

Downloads

The operating systems that are natively compatible with this product.

Indicates the specific revision of the product. Most products use year-based versioning.

Included Editions

Indicates the software editions that are included in the download option.

Indicates whether the download includes 32- or 64-bit software. This value does not refer to your OS.

Language used in the software user interface.

Disclaimer: The Third-Party Add-Ons for LabVIEW on this page are offered by independent third-party providers who are solely responsible for these products. NI has no responsibility whatsoever for the performance, product descriptions, specifications, referenced content, or any and all claims or representations of these third-party providers. NI makes no warranty whatsoever, neither express nor implied with respect to the goods, the referenced contents, or any and all claims or representations of the third-party providers.

Technical Support: Contact

Release Date
Included Versions
Supported OS
Language
Checksum

Note: Install JKI VI Package Manager (VIPM) before installing this product. VIPM helps you discover, create, and install LabVIEW add-ons.

Note: Install NI Package Manager (NIPM) before installing this product. NIPM helps you install, upgrade, and manage NI software.

File Size
