MT Detect CPM
Demodulates a CPM-modulated complex baseband waveform and returns the demodulated information bit stream. This node attempts to remove carrier and phase offset by locking to the carrier signal.
Inputs/Outputs
input complex waveform
The modulated complex baseband waveform data.
t0
Trigger (start) time of the Y array.
Default value: 0.0
dt
Time interval between data points in the Y array.
Default value: 1.0
Y
The complex-valued signal-only baseband modulated waveform. The real and imaginary parts of this complex data array correspond to the in-phase (I) and quadrature-phase (Q) data, respectively.
CPM system parameters
Parameter values defining the CPM system. Wire the CPM system parameters cluster of MT Generate CPM System Parameters (M) or MT Generate CPM System Parameters (map) to this cluster. Do not alter the values.
samples per symbol
An even number of samples dedicated to each symbol. Multiply this value by the symbol rate to determine the sample rate.
Default value: 16
symbol map
A two-dimensional array of desired frequency deviations. Each column corresponds to a symbol, with the binary representation of the column index being the mapped bit-representation of the symbol. Each row corresponds to a modulation index in the order in which it appears in the modulation index, h(i) parameter of MT Generate CPM System Parameters (M) or MT Generate CPM System Parameters (map).
Default value: Empty array
synchronization parameters
Parameter values describing the synchronization sequence and the range of bits over which to search for the sequence. Wire the CPM synchronization parameters cluster returned by MT Generate CPM Synchronization Parameters (bit array) or MT Generate CPM Synchronization Parameters (number array) to this cluster.
expected sync location
The expected location of the first symbol of the sync sequence.
This value is an index to the input complex waveform. A value of -1 searches the entire input complex waveform and ignores the sync location uncertainty parameter.
sync sequence
The mapped symbol pattern. Although the data type is complex, only the real portion is used.
The real portion of the mapped symbols is the frequency deviation of the symbol value, and the imaginary portion is 0. To prevent false synchronization, configure this pattern so that there is a low probability of accidental correlation to nonsynchronized parts of the data stream. If this parameter is left empty, the signal is still demodulated.
sync location uncertainty
Number of symbols before or after the expected sync location where the first symbol of the sync sequence may be located. The node ignores this parameter if the expected sync location parameter is set to -1.
Default value: 10
sync indent
Distance that the sync sequence is indented into the information block.
The distance is the number of demodulated symbols preceding the sync sequence. For example, a value of 10 indicates that the output bit stream consists of 10 data symbols, followed by the sync sequence, followed by the remaining data symbols.
Default value: 0
error in
Error conditions that occur before this node runs.
The node responds to this input according to standard error behavior.
Default value: No error
matched filter coefficients
An ordered array containing the desired matched filter coefficients. Wire the matched filter coefficients parameter of MT Generate Filter Coefficients to this parameter. When generating the filter coefficients, ensure that the value of the matched samples per symbol parameter of MT Generate Filter Coefficients is equal to the value of the samples per symbol element of the CPM system parameters cluster that is passed to this node.
Dependency on reset? Input
When reset? is set to TRUE, there is a transient response of half the filter length at the start of the demodulated signal, and the returned data is shortened by approximately half the filter length. When reset? is set to FALSE, the VI uses data from the previous iteration to prime the filter, hence eliminating the transient.
reset?
An ordered array containing the desired pulse-shaping coefficients. This parameter is used internally to reproduce the ideal waveform for making measurements. Wire the pulse shaping filter coefficients parameter of MT Generate Filter Coefficients to this parameter. When generating the filter coefficients, ensure that the value of the pulse shaping samples per symbol parameter of MT Generate Filter Coefficients is equal to the value of the samples per symbol element of the CPM system parameters cluster.
flush buffers?
A Boolean that determines whether to flush samples from the input complex waveform that are delayed due to the FIR filters used in the demodulation algorithm. Set this parameter to TRUE during single-shot operations and during the last iteration of continuous operations.
| TRUE | Destroys the internal states of the algorithms such that you cannot perform continuous processing on the signal during subsequent iterations. If flush buffers? is set to TRUE, you must set reset? to TRUE on the subsequent iteration. |
| FALSE | Stores the internal states of the algorithms so that you can perform continuous processing on the signal during subsequent iterations. |
Default value: FALSE
output bit stream
The demodulated information bit stream.
sync found index
Symbol index within the input complex waveform where the peak correlation to the sync sequence was found. If no sync sequence is specified in the synchronization parameters cluster, the sync found index parameter returns the offset from the start of the input complex waveform to the first complete symbol.
error out
Error information.
The node produces this output according to standard error behavior.
