RM-26999

Starting at $12,965.00
Part number(s):
786328-01

4-Channel Power Measurements Conditioner

Overview

The RM-26999 is a rack-mounted, signal conditioning device that connects to several simultaneous-sampling multifunction I/O devices for power measurements. It features four voltage input channels with peak voltages up to 2,000 V and four current transducer ports for current measurements. The current transducer ports are optimized for flux-gate transducers by providing all the power, communication, and signal lines required for accurate measurements.

Included Items

  • RM-26999
  • 2-Pin, COMBICON plug (773156-01)
  • Safety, Environmental, & Safety, Environmental, & Regulatory documentation

RM-26999 Details

Ask an expert
Part Numbers (1) Price
786328-01

NI Lead Time
6-7 weeks

RM-26999 Accessories and Software

  • Model (Part Number)
    Description
    Compatible Part Numbers
    PXIe-6376 (781475-01)
    PXIe-6376, 3.5 MS/s/ch Multifunction I/O Module (8 Simultaneous AI, 24 DIO, 2 AO)

    Accessory
    786328-01
    View Product Details
    PXIe-6366 (781057-01)
    PXIe-6366, 2 MS/s/ch Multifunction I/O Module (8 Simultaneous AI, 24 DIO, 2 AO)

    Accessory
    786328-01
    View Product Details
    PXIe-6356 (781053-01)
    PXIe-6356, 1.25 MS/s/ch Multifunction I/O Module (8 Simultaneous AI, 24 DIO, 2 AO)

    Accessory
    786328-01
    View Product Details
  • Model (Part Number)
    Description
    Compatible Part Numbers
    SHDB9M-DB9F-BNCM Cable (786668-05)
    SHDB9M-DB9F-BNCM, Current Transducer Shielded 9-Pin D-SUB Cable with BNC, 5 m

    Accessory
    786328-01
    View Product Details
    SHDB9M-DB9F-BNCM Cable (786668-02)
    SHDB9M-DB9F-BNCM, Current Transducer Shielded 9-Pin D-SUB Cable with BNC, 2 m

    Accessory
    786328-01
    View Product Details
    SHDB9M-DB9F Cable (786879-03)
    SHDB9M-DB9F, Current Transducer Shielded 9-Pin D-SUB Cable, 3 m

    Accessory
    786328-01
    View Product Details
    SHC68-68-EPM (192061-02)
    SHC68-68-EPM Shielded Cable, 68-D-Type to 68 VHDCI Offset, 2 m

    Accessory
    786328-01
    View Product Details
  • Model (Part Number)
    Description
    Compatible Part Numbers
    SHDB9M-SHDB9F Shunt (786897-0R5)
    SHDB9M-DB9F-SHUNT, Precision 0.5 Ohm Resistor DB9 Male and DB9 Female Connections

    Accessory
    786328-01
    View Product Details

Resources

RM-26999 User Manual(s)
RM-26999 Calibration Procedure(s)
RM-26999 Dimensional Drawing(s)
RM-26999 Product Certification(s)
RM-26999 Letter of Volatility
RM-26999 Specifications
