PXIe-4339

Name: PXIe-4339
Brand: National Instruments
Price: 7554 USD
Availability: InStock

Starting at $7,554.00

Part number(s):

783531-01

25 kS/s, 24-Bit, 8-Channel PXI Strain/Bridge Input Module

Overview

The PXIe-4339 is a universal bridge input module ideal for test cell installations requiring both accuracy and flexibility. Completely configurable through software, each channel can take bridge-based measurements and direct voltage measurements. Eight input ranges in ratiometric mode and four in voltage mode accommodate a wide variety of sensor types for your changing application needs. The PXIe-4339 also features per-channel wide bandwidth analog outputs, programmable excitation, Transducer Electronic Data Sheet (TEDS) support, and digital filtering.

Included Items

Module
Safety, Environmental, & Regulatory documentation

Part Numbers (1) Price	783531-01


NI Lead Time	12-13 weeks
Analog Input Voltage Range	-0.1 V to 0.1 V -0.2 V to 0.2 V -0.5 V to 0.5 V -10 V to 10 V -20 mV/V to 20 mV/V -40 mV/V to 40 mV/V -50 mV/V to 50 mV/V -80 mV/V to 80 mV/V -200 mV/V to 200 mV/V -10 mV/V to 10 mV/V -4 V to 4 V
Maximum Sample Rate	25.6 kS/s
Maximum Number of Differential Analog Input Channels	8
Bridge Configurations	Quarter Bridge#Full Bridge#Half Bridge
Bridge Resistance	350 Ohm#120 Ohm#1000 Ohm
Supported Hardware Platform	PXI
Bus Connection	PXI Express
Current Sensitivity	—
DC Current Range	—
Max DC Sink Power	—
Max DC Source Power	—
Number of SMU Channels	—
Pulsed Current Range	—
SourceAdapt	—
Voltage Range	—
Product Description	NI PXIe-4339 8-Ch,24-bit,25.6kS/s Bridge and Voltage Input Module

PXIe-4339 Accessories and Software

Cables (3)

Model (Part Number) Description	Compatible Part Numbers
SH96-96-2 (157350-05) SH-96-96-2, Cable for PXIE-4302, PXIE-4303, and PXIE-4339 to Rackmount Terminal Blocks, 5 Meters	783531-01	View Product Details
SH96-96-2 (157350-03) SH-96-96-2, Cable for PXIE-4302, PXIE-4303, and PXIE-4339 to Rackmount Terminal Blocks, 3 Meters	783531-01	View Product Details
SH96-96-2 (157350-01) SH-96-96-2, Cable for PXIE-4302, PXIE-4303, and PXIE-4339 to Rackmount Terminal Blocks, 1 Meter	783531-01	View Product Details

Software (2)

Product (Part Number) Description	Recommended use cases
FlexLogger Professional (785748-3501) FlexLogger Professional, Subscription License, Download	Recommended for automated, extensible data logging with NI data acquisition (DAQ) hardware. Automate tests using alarms, triggers, and events, and expand capabilities with plug-ins. Key Features Multichassis synchronization—Synchronize multiple NI chassis for accurate, time-aligned measurements across high channel counts. Logging triggers—Start, stop, or segment data recording automatically based on sensor thresholds or other conditions to capture only what matters. Events—Respond to specific occurrences during a test, such as activating equipment when a condition is met (for example, start cooling fans when temperature exceeds a limit). Automation APIs—Control and monitor FlexLogger from external applications (Python, NI LabVIEW, or NI TestStand), enabling integration into larger automated test systems. Calculation channels—Perform real-time math on acquired data (averages, RMS, custom formulas) to track derived measurements as the test runs. Plug-ins—Extend FlexLogger with custom LabVIEW or Python plug-ins to integrate third-party hardware, perform custom analysis, or connect to lab systems. CAN/LIN logging—Acquire and log automotive network data alongside sensor measurements for complete vehicle or subsystem testing.	View Product Details
LabVIEW+ Suite (788509-35) NI LabVIEW+ Suite, Subscription License, Download	Recommended for engineers building full test and validation systems where modular code development and higher-level frameworks are needed to accelerate development for shorter time to market. The LabVIEW+ Suite includes the following products: NI LabVIEW—Provides a graphical programming environment for test system development, enabling connectivity to any instrument and fully integrated user interfaces. NI TestStand—Eliminates the need for time-intensive in-house sequencer development and maintenance by providing an off-the-shelf test management software for validation and production test. NI DIAdem—Saves engineers hundreds of hours of manual data analysis and report creation with automation. NI FlexLogger™ software—Simplifies data acquisition and data logging with interactive measurement setup for NI DAQ hardware. NI InstrumentStudio™ software—Provides a central location for configuration, measurement, and automation.	View Product Details
